IKAR HRA

Harnesses

• Model: HRA
• Certification: EN 360:2002, EN 1496:2007
• Housing: Aluminium or Plastic
• Lifeline: Galvanized steel rope

Height Safety Devices (IKAR with Rescue Hoisting Facility)

• Device Type: IKAR height safety devices with a rescue hoisting facility (type HRA)
• Winch Unit: The device includes a winching unit, which can be easily snapped in by a second person for rescue after a fall.
• Use Case: Particularly useful in cases of unconsciousness due to gas exposure (e.g., in shafts or channels).

Height Safety Devices Type HRA

• Rescue Capability: The person who has suffered an accident can be rescued quickly and safely using the winching unit.
• Durability: The unit is fully enclosed and has no wearing parts.
• Materials: All parts are made from stainless steel, aluminum, or shock-proof plastic.
• Steel Rope Lengths: Different lengths available to ensure suitability for every application.
• Customization: Special rope lengths and V2A stainless steel or Dyneema ropes can be requested.

Lanyards

• Safety Standard: The height safety devices with rescue hoisting facilities meet very high safety standards.
• Technology: Proven and globally recognized for excellence.

Descent Devices

• Certifications:
• CSA Z259.2.2-98
• ANSI/ASSE Z359.14-2012/LE

Explanation for the Device Names

• H: Height Safety Device
• R: Rescue hoisting device
• S: Let-down function
• P: Plastic housing
• Number: Length of the retractable connecting element

Tripod and Accessories

• Note: These are accessories that complement the height safety devices.

Cantilever Arms and Accessories

• Note: Additional accessories for cantilever arms related to height safety devices.

IKAR Height Safety Devices with Rescue Hoisting Facility and Winch Chain

• Feature: The winch chain enables easy use of the winch in the HRA device, even if the fastening point is located at a very high position.
• Application Example: Used in situations like entering shafts.
• Setup: The height safety device is mounted stationary on a vehicle, making it difficult to use a hand-crank device for rescue when the load fastening is very high.

Eyebolt AP-Fix

• Description: This is an accessory for the installation and securing of height safety devices.

Deflection Roller

• Description: An accessory used in the operation of height safety devices to redirect the line.

HRA Wall Holder

• Feature: A quick-release holder for wall mounting of HRA devices.
• Order No.: 41-54 / WHG
• Length Range: 9.5 – 33 m
